Door panel polyester sponge
Specific Datasheet | |||||||||
Foam Type |
Density Kg/m³ |
Tensile Strength Kpa |
Elongation % |
Tear Strength N/mm | (40%) Compression Resistance (40%) KPA | (22h, 70℃) Compression Set (22h, 70℃) % | (16h, 100℃) Fogging (16h, 100℃) MG |
Odor Grade |
Anti-Hydrolysis |
DIN EN ISO 845 | DIN EN ISO 1798 | DIN EN ISO 1798 | DIN EN ISO 8067 | DIN EN ISO 3386 | DIN EN ISO 1856 | DIN 75201-B | VDA 270 | PV 3959 | |
| ZD303DW | 29±3 | 29±3 | ≥200 | ≥0.5 | 4.0±1 | ≤20 | ≤2.0 | ≤3.5 | PASS |
ZD364EW | 35±3 | ≥170 | ≥200 | ≥0.3 | 4.5±1 | ≤10 | ≤2.0 | ≤3.5 | |
ZD364DW | 35±3 | ≥170 | ≥200 | ≥0.3 | 4.5±1 | ≤10 | ≤2.0 | ≤3.5 | PASS |
ZD435DW | 42±4 | ≥170 | ≥230 | ≥0.4 | 5.0±1 | ≤10 | ≤2.0 | ≤3.5 | PASS |
